EX4-24 semi automatic block making machine

EX4-24 semi automatic block making machine

Exmork EX4-24 semi automatic block moulding machine can produce different sizes of hollow blocks, solid bricks, interlocking pavers, hourdis, habiterra block by changing molds

1. Production capacity:

Block size	Number of blocks produced at a time	8 hours Production capacity
8 inches: 400-200-200mm	4	3840
6 inches: 400-150-200mm	5	4800
4 inches: 400-100-200mm	7	6720
225-112.5-80mm curved brick	12	11520
200-160-80mm I-shaped brick	8	7680

2. Introduction:

This machine mainly uses three-phase electricity as power.The production cycle of this machine is 24-30 seconds, and the pallet size is 850/880-550-20mm. The machine can be used with a mixer, conveyor belt and stacker, and the bricks are transported with a matching brick forklift.The machine mold is produced according to the shape and size provided by the customer. The machine can produce hollow bricks, solid bricks, floor bricks, pavement bricks, curbstones and special-shaped bricks of different sizes by changing the mold.

3. Design of blocks, interlocking paving bricks, and curbstones for reference:

4. Technical Information

Model No.	EX4-24
Forming Cycle	24-30 Second
Vibration Frequency	4200-4800r/min
Vibration Force	45-55KN
Pallet Size	880/850-550-20mm
Total Power	13.45KW
Workers	5-6 workers
Workshop Size (Min.)	15m Length, 4m Width, 4m Height
Block Machine Size	2100mm(L)-1900mm(W)-2350mm(H)
Host Block Machine Weight	2400 KGS
JQ350 Mixer Capacity	350L
Generator	50KW
